Sony PocketStation

Overview

Development Tools

• The professional tool from ARM, called the ARM Developer Suite.  You can get a free copy of the evaluation version from ARM just by filling out a form.  The evaluation version is fully capable but limited to 45 days.  This suite runs on Win32.
• There is a semi-professional development suite available from SN Systems, a maker of development software for consoles.  I found this software on a third-party web page.  One would assume that the software comes with the full Playstation development suite.  However, I do not want to purchase the development suite (obviously), and I cannot find a page which claims this tool.  That being said, the software is based on gcc, and as I'm sure you all know, that means it's GPL.  So without further ado, here is some development software.
• There is also available a version of gcc which has been compiled and made available for BSD.  This is what is commonly used in Japan.  I don't know much about this software, since all the information available about it is in Japanese.  All I can do is point you to the following web page, which discusses the software.

Bugs

• The compiler compiles arbitrary signed division to an assembly call to a routine, '_divsi3'. Unfortunately this routine is not included - no external libraries are. I attempted to write my own copy and include it, however despite my best efforts I could not get it to work - it correctly evaluates 29/10 = 2, but it says 30/10 = 2 as well. If you want to work on it, it's called 'divide' and it's in 'newstart.s'. So, for the moment, the compiler itself is only capable of doing static divisions (i.e. #define FOO 36 / 9) or simple unsigned divisions by powers of 2, which are encoded as shifts. I have written my own C routine for doing arbitrary unsigned division and remainder, but it is slow.
• The compiler doesn't really understand signed quantities. It doesn't complain, but it doesn't get the right answer either. Signed comparisons almost always fail and definitely don't do what you want. Comparing less than 0 doesn't even work. Simple math - addition and subtraction - seems to work, but signed multiply doesn't. For comparing signed quantities I add a large positive number to both sides - that seems to work, unless there is overflow, of course. I recommend avoiding negative numbers if possible.
• Global non-const variables are not initialized, even if you ask that they be. The solution to this is simple - initialize them first thing in main.
• Global arrays of 8-bit quantities (bytes) are not initialized properly even if they are const. They also don't seem to work that well. If you really want to use arrays of bytes, try "initializing" them in assembly, and writing byte access routines. I have found that the "unsigned char" datatype is unreliable, especially when dereferencing a pointer.
• In the emulator, you can rest a timer's count after you start it. In the real PocketStation, you can't, and if you try it's just ignored. Also, the emulator's timer is approximately 3-4 times as fast as the real PocketStation, although it's not consistent and may very well vary depending on the machine you run it on.

Display

#define VIDEO_MEMORY 0xD000100
void DrawPixel(unsigned int x, unsigned int y)
{
    if((x < 32) && (y < 32))
        VIDEO_MEMORY[31 - y] |= (1 << (31 - x));
}

This routine 'draws' (i.e. fills in) the pixel at (x,y) where (0,0) is in the upper-left hand corner.  Note that since the memory is arranged in reverse order, we must use 31-y and 31-x.  Some things to notice about this routine:

• This routine only draws a pixel.  To clear a pixel, use VIDEO_MEMORY[31 - y] &= ~(1 << (31 - x)).  To reverse a pixel, use VIDEO_MEMORY ^= (1 << (31 - x)).
• This routine is not double-buffered, which is definitely recommended.  A good way to achieve double-buffering is to set up 32 unsigned ints of ram and write to that.  Then use a routine once per logical round which blits the data.  One such routine is included in my tic-tac-toe program, called BlitScreen.
• If you're writing a full-screen image, don't use this!  Define the image as 32 ints and blit the data directly onto the screen - remembering that the top row is memory location 31.  This routine is called DrawScreen in my code.
• Note that with some pocket devices - the VMS, notably - 'keeping up with' the display is a real concern.  Some devices also require that the data in the video memory be constantly 'refreshed', a la the Atari 2600.  That is not the case here - the processor is plenty fast, and the video ram is not volatile.

Buttons

The buttons are attached to a port, location 0x0A000004.  When one of the buttons is pressed, a bit of this memory location is set corresponding to the following table:


7	6	5	4	3	2	1	0
Other Purposes	Other Purposes	Reset?/Unused	Up	Down	Left	Right	Fire/A

What this means is that, for example, while the down button is pressed, bit 3 of memory location 0x0A000004 is set to 1.  These presses are transient - that is, as soon as down is released, bit 3 goes back to zero.  Consider the following routine, taken partially from the SN systems demo code:

#define BUTTON_MEMORY 0x0A000004
unsigned int getButtons()
{
    return (*((unsigned int *) BUTTON_MEMORY)) & 0x0000001F;
}

Note that in this, standard, mode of operation, the button presses do no generate an interrupt.  The ARM7TDMI has a modern, complex interrupt system which can be used to generate interrupts when these buttons are pressed.  If you want to generate a button interrupt, you must do the following two things:

1. Write an interrupt handler for the corresponding interrupt.
2. Register it in the system interrupt table.
3. Activate the desired interrupt.
4. De-activate it when the program exits.

To enable an interrupt, write a "1" bit to the corresponding bit location of IRQ_ENABLE using the above chart.  For example, to enable all of the button interrupts, write 0x1F to IRQ_ENABLE.  The "volatile" portion of the description means that these written values don't stick.  Make sure to use the "volatile" keyword if using C to ensure that writes occur.  Disabling the interrupt involves writing a 1 to IRQ_DISABLE at the corresponding bit.  After the interrupt has been serviced, write a 1 to the corresponding bit of IRQ_CLEAR.  All interrupts use the same interrupt handler (with a few exceptions, see interrupts above).  See interrupt handling, above.

Clock

unsigned int t, hh, mm, ss;
t = *((volatile unsigned int *) 0xb800008;
DrawNumber(0, 0, (hh & 0x00F00000) >> 20);
DrawNumber(4, 0, (hh & 0x000F0000) >> 16);
DrawNumber(8, 0, 10);                         // Draw a colon
DrawNumber(12, 0, (mm & 0x0000F000) >> 12);
DrawNumber(16, 0, (mm & 0x00000F00) >> 8);
DrawNumber(20, 0, 10);
DrawNumber(24, 0, (ss & 0x000000F0) >> 4);
DrawNumber(28, 0, (ss & 0x0000000F));

Displays a clock.  The time portion of the clock corresponds to data location 0xb800008.  The layout of this 32-bit memory location is, in BCD (binary coded decimal):


7	6	5	4	3	2	1	0
0xF0000000	0x0F000000	0x00F00000	0x000F0000	0x0000F000	0x00000F00	0x000000F0	0x0000000F
Unused	Day of the week	Hour, tens digit	Hour, ones digit	Minute, tens digit	Minute, ones digit	Seconds, tens digit	Seconds, ones digit

There is a similar memory location at 0xb800000 which contains the date, but I'm not sure in what format:


7	6	5	4	3	2	1	0
0xF0000000	0x0F000000	0x00F00000	0x000F0000	0x0000F000	0x00000F00	0x000000F0	0x0000000F
Reserved	Reserved	Year, high digit?	Year, low digit?	Empty	Month	Day, top 4 bits	Day, bottom 4 bits

I'll do some more experimentation to see what the date business is.  In fact, the Pocket Station has a whole Real-Time Clock (or RTC) mechanism.  There is a RTC-based counter capable of operating at 1/sec or at 4000/sec, but I don't know exactly how it works yet.

Here is some code which operates the clock and shows the time.  With a little more effort it could show the date as well.

Infrared

• IrDA.  IrDA is a modern infrared-based protocol for transmitting large (read: computer-oriented) amounts of data quickly.  It is bidirectional.  You may think of it as a sort of "XModem" for infrared devices.  Although it has several configurable options (for example, there are two available speeds), it specifies the pulse lengths, carrier waves, etc.  This sort of protocol is what you would use if you wanted 2 PocketStations to talk to each other.  It works best when the data to be sent is "discrete" - i.e., I want to send my high-score table to you, as opposed to "continuous", as in a real 2-player game, like Pong.
• 'Legacy'.  Legacy is a bad name for this because it is still very much in use.  This is the system used by most consumer devices - TVs, stereos, etc.  In this mode, there is no specified pulse length, carrier wave - anything.  Just 'on' and 'off'.  Different devices have different ways of coding pulses, and there is no real "standard".

The purpose of pIRDA_BEAM is to turn the actual beam on/off.  Writing a 1 to the LSB of this address seems to turn on the beam, a 0 turns it off.  Based on my disassembly of the Chocobo World program, however, I have two theories about this memory location:

1. Writing a 1 to the LSB turns the beam on, a 0 turns it off.  The rest of the bits don't matter.
2. Whatever is written to this location, the IrDA module attempts to send out - so for exampe, if 0x77777777 is put here, a pulse is sent out of mixed 1s and 0s.

The control location supports a number of operations designed around the IrDA module.  Here is a partial list:


Value	Name	Purpose
IR_MODE_RECV	0x00	Put in receive mode
IR_MODE_SEND	0x01	Put in send mode
IR_STOP	0x02	Turn off the IrDa module - see below
IR_SEND_READY	0x04	??
IR_RECV_READY	0x08	??

The purpose of some of these is confusing to me.  I know that, to send a beam, the IR module must be in send mode.  I also know that there is an interrupt which can be caused by the Infrared module - and I would assume that this is used to trigger that a character has been read in RECV mode.  This interrupt is 0x1000 (see interrupts elsewhere in the document).  The last two entries are a mystery to me.  Chocobo World doesn't seem to use them.  They might be synchronization primitives - I don't know.  IR_STOP is also confusing.  Generally it is used when a program exits.  What I don't know is - does this disable the beam entirely, or just disable the IrDA logic around the beam?

So there are still many questions.  But for those of you who want to experiment with making two-player games, this should be enough to get started.


A word about resolution and intensity

Personal Contributions

• An ARM7TDMI disassembler.  Here is the source code, and here is a Windows binary.
• The game of tic-tac-toe, for the pocket station.  A good starter. Here is just the binary, in MCX format.
• Minesweeper for the pocketstation, complete with scrolling playfield. Here is the binary. Note: there is a bug in this game. It's nasty. Play for a while and you'll find it. Anyone who can fix it earns my undying gratitude. I find it crashes once every 5 or 6 games, and always at the beginning. You may have to reset your pocketstation.
• A very simple clock which shows the time. Here is the binary. This clock is very simple but instructional. I think the year is displayed incorrectly - somebody fix it! Plus the code contains timing portions which can be used to get accurate timings of timer0.
• A clone of space invaders. Here is the binary.
• An infrared test program, which is a first attempt at making a remote control.  It doesn't work.
